Categories: Deep Groove Ball Bearing
|
d |
90 mm | Bore diameter |
|
D |
190 mm | Outside diameter |
|
B |
43 mm | Width |
|
d1 |
≈121.15 mm | Shoulder diameter inner ring |
|
D2 |
≈166 mm | Recess diameter outer ring shoulder |
|
r1,2 |
min.3 mm | Chamfer dimension |
|
da |
min.104 mm | Abutment diameter shaft |
|
Da |
min.171 mm | Abutment diameter shaft |
|
Da |
max.176 mm | Abutment diameter housing |
|
ra |
max.2.5 mm | Fillet radius |
| Basic dynamic load rating |
C |
151 kN |
| Basic static load rating |
C0 |
108 kN |
| Fatigue load limit |
Pu |
3.8 kN |
| Reference speed | 7 500 r/min | |
| Limiting speed | 4 800 r/min | |
| Calculation factor |
kr |
0.03 |
| Calculation factor |
f0 |
13.3 |
| Mass bearing | 4.9 kg |
